PCB pin strip
Approvals
Request STP/BIM File
The tab connector 931-FST with tabs 2,8 x 0,8 mm can be used both with plug connector 930-FL or 938-FLDS and to connect individual wires with tab receptacles B 2.8-DIN 46 247 whose crimped points must be insulated. The tab connector is inserted in the plug connector 930-FL in direction of the wire entrance, which minimizes the space requirements on the PC board compared to the combination with pin strip 931-SLS or 931-SLR. The receptacles are not parts of our production program.
971SLS**
