328 101A Terminal Block
Screw connection
Approvals
Request STP/BIM File
The socket terminal strip 328 is available in 17.5mm pitch with 1-12 pole design and can be easily stripped to the desired number of poles. This version is well suited for large cross-sections, with a current rating of 101A and a voltage rating of 750V. One fixing hole is located between every pole. The flexible polyamide moulding can even be mounted on curved surfaces.
Data sheet
- Mouldings
- PA, black, UL 94, V-2
- Current Rating
- 101A
- Voltage Rating
- 750V
- Inserts
- Nickel plated brass
- Screw tightening torque
- 2.6 Nm
- Conductor size
- 25 mm²
- Wire stripping length
- 13 mm ± 1 mm
- Screws
- M5; Zinc plated steel, Blue passivated
- Pitch
- 17.5mm
- Number of Poles
- 1-12
- Temperature range
- -30°C up to 120°C
